About Yofil Ltd

Founded in 2016 by Chris May and John Shackleton in Warrington (Cheshire), British company Yofil Ltd is a recognized expert in the design and manufacture of advanced automatic wheel and chassis washing systems for commercial and construction vehicles. Leveraging deep technical expertise and extensive industrial experience, the Yofil Ltd team creates modular, flexible solutions that enable major developers and industrial enterprises to strictly fulfill their environmental obligations.

Truck Wheel Washing Systems

Professional mobile Eco Warrior water recycling systems for automatic cleaning of wheels, chassis, and undercarriages of heavy construction, quarry, and commercial specialized vehicles. Effective protection of public roads against mud track-out from construction sites.

Eco Warrior EW4

Compact Solution
Wash Platform:4 meters
Settling Tank:6 meters
Ramps Included:4 meters

Designed specifically for sites with low to medium traffic intensity, where construction vehicle flow is not continuous, but regular and high-quality wheel cleaning is strictly required.

Technical Datasheet →

Eco Warrior EW6

Universal Model
Wash Platform:6 meters
Settling Tank:6 meters
Ramps Included:4 meters

The most sought-after modification, suitable for most major construction sites. The 6-meter platform length allows wheels to make more full rotations under the nozzles, ensuring an optimal cleaning cycle.

Technical Datasheet →

Eco Warrior EW8

For Heavy-Duty Conditions
Wash Platform:8 meters
Settling Tank:6 meters
Ramps Included:4 meters

A flagship engineering solution for extreme conditions: quarries, industrial plants, and large-scale infrastructure projects with high traffic intensity. Guarantees the maximum number of wheel revolutions and maximum cleaning efficiency.

Technical Datasheet →

Installation Conditions & Engineering Requirements

Base Requirements
  • Installation Type: Surface-mounted, rapid modular assembly (does not require pouring a complex recessed concrete pit).
  • Surface: Compacted, durable crushed stone base.
  • Thickness: Minimum layer — 300 mm.
  • Load Capacity: Must withstand heavy commercial vehicle traffic (at least 200 kN/m²).
Power Supply
  • Operating Voltage: 415 V, stable 3-phase connection.
  • Connection Type: Plug-and-Play standard quick-connect fittings (excluding the main distribution panel).
  • Generator: For off-grid operation, a generator with a capacity of at least 45–60 kVA is recommended.
Water Consumption & Losses
  • Total Tank Volume: The recirculation system includes a 24,000-liter storage tank.
  • Average Losses: 50–150 liters per vehicle (carry-over on wheels, evaporation).
  • Top-up Requirements: From 2–5 m³ per day under average loads up to 10 m³ per day under high intensity.
Water Recycling Operating Principle & Settling Tank Cleaning
The system operates on a closed-loop cycle: contaminated water from the platform enters the settling tank, where sediment (sludge) settles to the bottom, and clarified water is directed back to the nozzles through a baffle system. Silt accumulation ranges from 0.5–1.5 m³ per week (medium load) up to 3–5 m³ per week (heavy-duty conditions). The settling tank is cleaned using a vacuum tanker (sludge gully emptier) or an excavator. Service frequency: under low loads (<50 vehicles/day) — once every 2–4 weeks; under medium loads — once a week; under high loads (>100 vehicles/day on clay soils) — 2–3 times a week.

Request a Quote

Melian Grupp specialists will prepare a detailed technical specification and cost calculation for the equipment, taking into account the architectural features of your site and your business requirements.



  • Official B2B quotation within 24 hours
  • Engineering consultation on utility and infrastructure preparation
  • Selection of the optimal options package based on your expected traffic volume
